Molex Connector Terminated Grey Colour Braiding Shielded Custom Cable

Brand Name : Power Cable

Model Number : TH-810115

Certification : UL, CSA, AWM

Place of Origin : Dongguan, China

MOQ : 3050 meters

Price : USD0.13~0.46 per meter

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10,000,000 meters monthly

Delivery Time : 5~10 working days

Packaging Details : 915 meters per carton, subject to the customized dimensions of product.

Type : Customized Cable

Feature : Braiding Shielded

Rated Temperature : 80 degree

Rated Voltage : 300V

Colour : Grey

Standard : 100% RoHS Compliant

Contact Now

Molex Connector Terminated Grey Colour Braiding Shielded Custom Cable



Customized Cable is the most featured products of Tongheng business. Molex Connector Terminated Grey Colour Braiding Shielded Custom Cable is created strictly following customers requirement. As the professional manufacturer, Tongheng staff engage to create customer the best quality cable. Molex Connector Terminated Grey Colour Braiding Shielded Custom Cable is one of the excellent example. Its remarkable advantage is braiding shielded.



Here below is the product properties:



End: molex connector terminated

Colour: grey

Shield: braiding

Spec to be customized per customers requirement.



Product parameters:



Flexible Cable Conductor Structure Insulation Thickness Nominal Diameter Screened Coverage Sheath Thickness Overall Diameter Current Capacity
AWG mm mm % mm mm A
2C 30 0.38 1.10 ≥65 1.15 5.00 0.4
2C 28 0.38 1.20 ≥65 1.15 5.30 0.6
2C 26 0.38 1.30 ≥65 1.15 5.40 0.8
2C 24 0.38 1.40 ≥65 1.15 5.70 1.5
2C 22 0.38 1.60 ≥65 1.15 6.10 2.5
2C 20 0.38 1.80 ≥65 1.15 6.50 6.0
2C 18 0.38 2.10 ≥65 1.15 7.10 10.0
2C 16 0.38 2.40 ≥65 1.15 7.70 19.0
3C 30 0.38 1.10 ≥65 1.15 5.30 0.4
3C 28 0.38 1.20 ≥65 1.15 5.50 0.6
3C 26 0.38 1.30 ≥65 1.15 5.70 0.8
3C 24 0.38 1.40 ≥65 1.15 5.90 1.5
3C 22 0.38 1.60 ≥65 1.15 6.50 2.5
3C 20 0.38 1.80 ≥65 1.15 6.80 6.0
3C 18 0.38 2.10 ≥65 1.15 7.40 10.0
4C 30 0.38 1.10 ≥65 1.15 5.50 0.4
4C 28 0.38 1.20 ≥65 1.15 5.70 0.6
4C 26 0.38 1.30 ≥65 1.15 6.00 0.8
4C 24 0.38 1.40 ≥65 1.15 6.40 1.5
4C 22 0.38 1.60 ≥65 1.15 7.70 2.5
4C 20 0.38 1.80 ≥65 1.15 7.20 6.0
5C 30 0.38 1.10 ≥65 1.15 5.70 0.4
5C 28 0.38 1.20 ≥65 1.15 5.80 0.6
5C 26 0.38 1.30 ≥65 1.15 6.00 0.8
5C 24 0.38 1.40 ≥65 1.15 6.40 1.5
5C 22 0.38 1.60 ≥65 1.15 7.00 2.5
6C 30 0.38 1.10 ≥65 1.15 5.90 0.4
6C 28 0.38 1.20 ≥65 1.15 6.30 0.6
6C 26 0.38 1.30 ≥65 1.15 6.70 0.8
6C 24 0.38 1.40 ≥65 1.15 7.00 1.5



Contact:



Thanks for your visit to our website. The above displayed parameters are just for reference. Please ask us for customized ones immediately if you have the different requirement.
